Synthesis of helical ladder polymers

Posted: 2019-5-20
Latest Research News

Abstract:
Researchers at Kanazawa University synthesized helical ladder polymers with a well-defined cyclic repeating unit and one-handed helical geometry, as they reported in the Journal of the American Chemical Society.


Ladder polymers — molecules made of adjacent rings sharing two or more atoms — are challenging to synthesize, because they require highly selective, quantitative reactions to avoid the formation of branching structures or of interruptions in the ring sequence in the polymer chain. Moreover, most existing strategies for the synthesis of ladder polymers suffer from severe limitations in terms of selectivity and quantitativity. Another important type of molecules are molecules with a helical structure (such as DNA and proteins), which play an important role in molecular recognition and catalysis. Thus, the fabrication of molecules that possess both a ladder and a helical structure could open up new applications of polymeric materials.

Tomoyuki Ikai, Timothy M. Swager and colleagues from an international collaboration started from triptycene, an aromatic hydrocarbon that is an achiral molecule, but from which chiral derivatives can be obtained by introducing substituents in the benzene rings in an asymmetric manner. Optically active triptycenes have practical uses as chiral materials, for example for chiral separation and circularly polarized luminescent materials. The researchers then used the chiral triptycenes as a framework to efficiently form single-handed helical ladder polymers using electrophilic aromatic substitution. Steric repulsion in the system resulted in the formation of one-handed twisted ladder units. The reactions were quantitative and regioselective (that is, there is a preferred direction of chemical bonding), which enabled the synthesis of optically active ladder polymers with well-defined helical geometry. No byproducts were detected.

Several techniques, including spectroscopy and microscopy techniques, were used to characterize the reaction products during synthesis, and molecular dynamics simulations were employed to understand the structure of the resulting molecules, confirming the right-handed helical ladder geometry. The researchers also measured the optical activity of the molecules.

The newly reported synthesis route will open up the synthesis of nanoscale helical ladder architectures and optically active chiral materials. “We believe that these ladder polymers, which can fall into a new category of helical polymers, represent a promising class of advanced materials for use as nanochannels for molecular/ion transport, organic electronics, specific reaction fields, and functional hosts through further modification of the backbone and pendant units,” commented the authors in the paper.







Figure.

Low pH environment induces conformational change of HA0. Conformational change of HA0 trimer in neutral and acidic condition mimics to the pH gradient from ER to secretory vesicles during viral assembly in cell membrane A construction of macro-scale architectures with a helical ladder shape is not even a challenge, but it’s a different story when it comes to a molecular scale. Here, the efficient synthesis of one-handed helical ladder polymers is established through a trifluoroacetic acid (TFA)-assisted intramolecular cyclization of chiral triptycenes.







Article
Triptycene-Based Ladder Polymers with One-Handed Helical Geometry

Journal: Journal of the American Chemical Society

Authors: Tomoyuki Ikai, Takumu Yoshida, Ken-ichi Shinohara, Tsuyoshi Taniguchi, Yuya Wada, and Timothy M. Swager

DOI: 10.1021/jacs.8b13865

Funder
This work was supported by the Japan Society for the Promotion of Science (JSPS) KAKENHI through a Grant-in- Aid for Scientific Research (C) (grant no. 17K05875). Work at MIT was supported in part by the Air Force Office of Scientific Research (grant no. 17RT0904).
